德國賀德克流量開關，HYDAC品牌

HYDAC賀德克流量開關HFS 2500電氣- 機械  中文描述

可用的版本：標準; ATEX

HFS2500系列HYDAC流量開關是基于位置無關的浮動變送器的測量原理。檢驗介質移動的彈簧加載浮于流動的方向，這取決于流速。

應用領域包括：

When the magnet inside the float reaches the preset position, the reed contact switches. In order to protect it against external influences, it is cast in a steplessly adjustable housing. The devices of the HFS 2500 series are available in two variants,

among others: - Cooling systems and circuits - Hydraulic systems - Pumps - Welding machines and laser plants - Medical technology - Pharmaceutical industry - Chemical industry - Research and development

Accuracy ± 5% or ± 10% FS

Free choice of installation position

High functional dependability

High switching accuracy

Stepless switching point adjustment by the user

High pressure resistance

Screw connection

ATEX version also available for explosion-hazard areas.

高開關精度

無級切換點調整用戶

- 冷卻系統和電路 - 液壓系統 - 泵 - 自動焊接設備和激光設備 - 醫療技術 - 醫藥行業 - 化工 - 研發

精度±5％或± 10 ％FS

自由選擇安裝位置

高性功能

one with 5% accuracy and one with 10% accuracy of the end value. Areas of application can be found in the monitoring of flow rates of fluid media (water / water-based), in the following areas,

耐高壓

螺紋連接

也可用于危險區域ATEX版本。

HYDAC賀德克流量開關HFS 2500電氣- 機械  英文描述

Available versions:

Standard; ATEX

The HYDAC flow switches of the HFS 2500 series are based on a position-independent float transmitter measurement principle.

The test medium moves a spring-loaded float in the direction of flow, depending on the flow rate. A reed contact is fitted outside of the device and thus also outside of the flow circuit.
